12U wall mounting cabinet, Dynamic 611x600x450 mm, color gray (RAL 7035)
12U wall mounting cabinet, Dynamic 611x600x450 mm, color gray (RAL 7035)
TECHNICAL DETAILS Safety class IP20 Lockable safety glass door with steel frame 483 mm (19") profile rails mounted at the... Read more
SKU: DN-19 12-U-3
(€175,45 Incl. VAT)€145,00
- Lowest price guarantee!
- Shipping from just €5.95
- Pay afterwards after 14 days
- 2 year warranty on your purchase
Can we help you with anything?
Do you have any questions or need advice? We are happy to help you!
Contact us!
Ask your question
Our product specialist is happy to help you find the right product.
Additional products
-
-
-
19 Inch 2U shelf for racks from 450 mm depth 88.5x483x352 mm, up to 25 kg, gray (RAL 7035)
(€30,01 Incl. VAT)€24,80
-
19 inch 2U shelf for racks from 450 mm depth 88.5x483x352 mm, up to 25 kg, black (RAL 9005)
(€33,64 Incl. VAT)€27,80
-
2U pull-out shelf for cabinets from 450 mm depth 88x483x352 mm, up to 30 kg, grey (RAL 7035)
(€91,96 Incl. VAT)€76,00
-
TECHNICAL DETAILS
- Safety class IP20
- Lockable safety glass door with steel frame
- 483 mm (19") profile rails mounted at the front and rear inside the rack, galvanized
- 483 mm (19") profile rails are depth-adjustable and equipped with height unit markings
- 0.8 - 1.2 mm thick sheet steel with high load-bearing capacity, powder-coated
- Cable entry at the rear, roof and bottom (pre-punched recesses)
- Roof is prepared for fan units (punched out entrances)
- Ventilation slots for active and passive ventilation and extraction
- 235° door opening angle
- 4 grounding points (bottom, side panel and front door) with protective cover
- Installation depth equipment min.-max.: 335 -380 mm
- Cabinet type: Wall mounted cabinet
- Colour: light grey, RAL 7035
- Depth: 450 mm
- Front door: Glass door, single opening
- Load capacity: 60 kg
- Side panels: Both sides
- Units: 12
- Width: 600mm
- IP protection class: IP20
- Mounted: yes
PACKAGE CONTENTS
- Ground wire set
- Mounting kit (screws, cage nuts, washers)
- 2 x keys
